Direct system block ice machine

HomeProducts › Direct system block ice machine

Focusun direct system block ice machine adopts edge-leading refrigeration industry technology. After direct heat exchange between refrigerant and water, in 5 to 8 hours, water is frozen out into ice. By that time, PLC controls the machine automatically into ice doffing process. Direct system utilizes hot Freon to defrost ice; so the defrosting process is fast. Aluminum evaporator adopts special technique to make sure the ice conforms to food grade standards; in other words, the ice can be directly consumed. Besides saving labor work and electricity consumption, its unique modular design saves much floor area than traditional brine system block ice machine.

Equipment features

  • The evaporator adopts special aluminum alloy plate which is more durable and meets food hygiene requirements.
  • The density of ice produced by direct system is 820~860kg/m3.
  • Energy saving : Power consumption is approx 64kw/Ton. Thus, less electricity is consumed.
  • Ice thawing and ice doffing are fully automatic, therefore no manual work is needed. The efficiency of this process guarantees time-saving.
  • The ice is doffed by batch and the whole ice-doffing process only takes 25 minutes.
  • The whole batch of ice blocks can be moved by forklift. Quick and convenient.
  • Module design makes the ice maker easy to transport, move and install.
  • Every direct refrigeration block ice machine can be designed and produced according to customer specific requirements.
  • The direct refrigeration block ice maker machine can be installed in 20ft or 40ft brand new container with other relevant equipments.

Direct refrigeration block ice machine technical parameter

Model Capacity Refrigerant Electricity consumption Installment power Operating weight Dimension
-- Ton/D -- Kw Kw Kg mm
FIB-05D 0.5 R22/R404A 2.055 2.5 560 1500×800×1800
FIB-10D 1.0 R22/R404A 4.850 6.0 960 1800×1200×2000
FIB-15D 1.5 R22/R404A 6.940 8.5 1260 2800×1200×2000
FIB-20D 2.0 R22/R404A 8.160 10.0 1460 2800×1400×2000
FIB-25D 2.5 R22/R404A 9.510 12.0 1660 3200×1400×2000
FIB-30D 3.0 R22/R404A 11.520 14.0 2180 3600×1400×2200
FIB-35D 3.5 R22/R404A 14.850 18.0 2100 3600×1650×2000
FIB-50D 5.0 R22/R404A 20.900 25.0 Unit:960 L1400×W1000×H1250
Evaporator:2860 L4800×W1000×H2250
Cooling tower:670 Ф1380×H2170
FIB-100D 10.0 R22/R404A 33.980 50.0 Unit:1680 L1800×W1000×H1450
Evaporator:2860×2 L4800×W1000×H2250
Cooling tower:670 Ф2000×H2410
FIB-150D 15.0 R22/R404A 59.150 75.0 Unit:2160 L2000×W1200×H1600
Evaporator:2860×3 L4800×W1000×H2250
Cooling tower:1120 Ф2175×H2565
FIB-200D 20.0 R22/R404A 85.550 105.0 Unit:2896 L2400×W1600×H1800
Evaporator:2860×4 L4800×W1000×H2250
Cooling tower:1300 Ф2650×H2645
FIB-250D 25.0 R22/R404A 94.050 120.0 Unit:3260 L3200×W1800×H2200
Evaporator:2860×5 L4800×W1000×H2250
Cooling tower:1630 Ф3050×H2780
FIB-300D 30.0 R22/R404A 113.550 150.0 Unit:3500 L3000×W2000×H2200
Evaporator:2860×6 L4800×W1000×H2250
Cooling tower:2730 Ф3300×H2785
Standard condition: Dry ball temperature is 33 ℃ and water inlet temperature is 20℃.
