Many of our customers run their businesses in the subtropical and tropical regions with high temperatures, where the inlet water temperature of ice machine can be relatively high, directly effecting the actual daily production of the ice making plant.
The inlet water can be cooled down to a suitable temperature by using a water chiller. Energy is saved this way, increasing the speed of ice-making and daily production.
In the areas where the ambient temperature is above 35 degree and the water temperature is above 20 degree, we recommend you to choose a water chiller, which will firstly cool down the water temperature, dropping it to 5-10 degrees.
Need help to find a suitable chiller? Please contact our colleagues from the technical department, direct at: kiki.feng@focusun.com. Their expert knowledge and years of experience will guarantee you the best choice of high-performance water chiller.
Item | Unit | ICW-4-35-10 | ICW-6-35-10 | ICW-12-35-10 | ICW-16-35-10 | |
---|---|---|---|---|---|---|
Power Supply | V/P/Hz | 380V/3P/50Hz | 380V/3P/50Hz | 380V/3P/50Hz | 380V/3P/50Hz | |
Refrigerant | R22 | R22 | R22 | R22 | ||
Standard Water Flow Rate | t/24h | 3 | 6 | 12 | 16 | |
Cooling Way | Air-cooling | Air-cooling | Air-cooling | Air-cooling | ||
Operation Condition | Ambient Temperature | ℃ | 40 | 40 | 40 | 40 |
Water Supply Temperature | ℃ | 35 | 35 | 35 | 35 | |
Water Outflowing Temperature | ℃ | 10 | 10 | 10 | 10 | |
Compressor | Manufacturer | Copeland | Copeland | Copeland | Copeland | |
Evaporating Temperature | ℃ | 5 | 5 | 5 | 5 | |
Condensing Temperature | ℃ | 48 | 48 | 48 | 48 | |
Cooling Capacity | kw | 5.03 | 7.82 | 16.60 | 22.00 | |
Operating Power | kw | 1.50 | 2.21 | 4.58 | 5.86 | |
Compressor COP/EER | kw/kw | 3.35 | 3.54 | 3.62 | 3.75 | |
Model | ZR22K3E-TFD | ZR34K3E-TFD | ZR72KCE-TFD | ZR94KCE-TFD | ||
Compressor Type | Vortex Compressor | Vortex Compressor | Vortex Compressor | Vortex Compressor | ||
Operating Power | Water Pump | kw | 0.125 | 0.150 | 0.370 | 0.550 |
Condenser Fan | kw | 0.7 | 1.1 | 1.5 | 1.5 | |
Compressor Power | kw | 1.50 | 2.21 | 4.58 | 5.86 | |
Total Running Power | kw | 2.325 | 3.460 | 6.450 | 7.910 | |
Installment Power | kw | 3 | 5 | 10 | 12 | |
Dimension | Contour Dimension | L×W×H(mm) | 1200×800×850 | 1200×1200×850 | 1600×1200×1000 | 1600×1400×1000 |
Water Inlet Dimension | Inch | 0.5 | 0.5 | 0.5 | 0.5 | |
Water Outlet Dimension | Inch | 0.5 | 0.5 | 0.5 | 0.5 | |
Water Tank | Material | SUS304 | SUS304 | SUS304 | SUS304 | |
Contour Dimension | L×W×H(mm) | 1200×400×400 | 1200×500×500 | 1200×500×1000 | 1200×500×1000 | |
Volume | L | 192 | 200 | 600 | 600 | |
Net Weight | Water Chiller | kg | 268 | 286 | 465 | 674 |
Water Supply Pressure Requirement | bar | 2~4 | 2~4 | 2~4 | 2~4 |
Item | Unit | ICW-20-35-10 | ICW-25-35-10 | ICW-30-35-10 | ICW-50-35-10 | |
---|---|---|---|---|---|---|
Power Supply | V/P/Hz | 380V/3P/50Hz | 380V/3P/50Hz | 380V/3P/50Hz | 380V/3P/50Hz | |
Refrigerant | R22 | R22 | R22 | R22 | ||
Standard Water Flow Rate | t/24h | 20 | 20 | 20 | 20 | |
Cooling Way | Air-cooling | Air-cooling | Air-cooling | Air-cooling | ||
Operation Condition | Ambient Temperature | ℃ | 40 | 40 | 40 | 40 |
Water Supply Temperature | ℃ | 35 | 35 | 35 | 35 | |
Water Outflowing Temperature | ℃ | 10 | 10 | 10 | 10 | |
Compressor | Manufacturer | Copeland | Copeland | Copeland | Copeland | |
Evaporating Temperature | ℃ | 5 | 5 | 5 | 5 | |
Condensing Temperature | ℃ | 48 | 48 | 48 | 48 | |
Cooling Capacity | kw | 29.3 | 33.4 | 42.9 | 69.8 | |
Operating Power | kw | 7.70 | 8.76 | 11.90 | 19.25 | |
Compressor COP/EER | kw/kw | 3.81 | 3.81 | 3.61 | 3.63 | |
Model | ZR125KCE-TFD | ZR144KCE-TFD | ZR190KCE-TFD | ZR310KCE-TFD | ||
Compressor Type | Vortex Compressor | Vortex Compressor | Vortex Compressor | Vortex Compressor | ||
Operating Power | Water Pump | kw | 0.55 | 0.75 | 0.75 | 1.00 |
Condenser Fan | kw | 2.2 | 3.0 | 3.5 | 4.5 | |
Compressor Power | kw | 7.70 | 8.76 | 11.90 | 19.25 | |
Total Running Power | kw | 10.45 | 12.51 | 16.15 | 24.75 | |
Installment Power | kw | 15 | 18 | 21 | 30 | |
Dimension | Contour Dimension | L×W×H(mm) | 1800×1600×1000 | 2500×1600×1000 | 2500×1600×1000 | 4200×1800×1000 |
Water Inlet Dimension | Inch | 0.75 | 0.75 | 0.75 | 1.00 | |
Water Outlet Dimension | Inch | 0.75 | 0.75 | 0.75 | 1.00 | |
Water Tank | Material | SUS304 | SUS304 | SUS304 | SUS304 | |
Contour Dimension | L×W×H(mm) | 1200×500×1000 | 1200×600×1200 | 1200×600×1200 | 1500×1000×1200 | |
Volume | L | 600 | 864 | 864 | 1800 | |
Net Weight | Water Chiller | kg | 824 | 1025 | 1168 | 1924 |
Water Supply Pressure Requirement | bar | 2~4 | 2~4 | 2~4 | 2~4 |
